RA-915M / RP-91NG
RA-915M mercury analyzer with RP-91NG attachment
The set of RA-915M with RP-91NG attachment is designed for direct determination of the mercury concentration in hydrocarbon gases. Analysis is performed continuously in a gas flow without preliminary accumulation on a gold trap.
RA-915M / RP-91NG
The set of RA-915M with RP-91NG attachment is designed for direct determination of the mercury concentration in hydrocarbon gases. Analysis is performed continuously in a gas flow without preliminary accumulation on a gold trap.
The set of RA-915M with RP-91NG performs analysis of natural gas sampled from a well, pipeline, cylinder, or Tedlar® bag. RP-91NG attachment optimizes gas flow to the analytical cell of RA-915M analyzer and eliminates interference from non-specific background molecular absorption. The technique provides a reliable measurement for the full range of mercury concentrations in natural gas, from ng/m3 to mg/m3.
RA-915M analyzer can be also used separately for real-time mercury measurement in ambient and indoor air. Other Lumex Instruments attachments are available to extend RA-915M functionality (PYRO-915+ for thermal decomposition technique, RP-92 for Cold Vapor technique).
Atomic absorption spectrometry at 254 nm wavelength with Zeeman correction for background absorption provides the most selective and sensitive analysis without matrix effects.
The highest selectivity of Zeeman technique and low detection limit allow direct analysis without preliminary precipitation and collection of mercury in absorption traps. As a result, the analyzer enables direct real-time determination of mercury in a hydrocarbon gas flow.
- Direct continuous real-time measurements
- Low limit of detection, highest selectivity
- Wide dynamic measurement range: more than 5 orders of magnitude
- No sample pretreatment, no reagents
- No compressed gases
- No pre-concentration on gold traps, no memory effect
- Analysis of gas and air in both laboratory and field conditions
- Low running and maintenance costs
RA-915M mercury analyzer with RP-91NG attachment is used for the direct determination of mercury concentration in in the natural gas. Mercury in hydrocarbons poses a number of technological and environmental problems including Hg exposure to humans, contamination of environment and equipment. Mercury also initiates corrosion of equipment and catalyst poisoning during gas transportation and processing. These effects have serious implications for the gas liquefaction and gas-processing technologies.
The standalone portable RA-915M is also used for background air monitoring, mercury surveys including continuous measurements from vehicles, indoor and outdoor pollution detection and mapping, demercurization control, occupational health and safety, geochemical exploration, etc.
RAPID is an efficient and intuitive software designed for the operation of RA-915M mercury analyzer with RP-91NG attachment. RAPID software fully complies with FDA 21 CFR Part 11 requirements.
It provides:
- data acquisition, processing, and reporting
- real-time visualization of selective and non-selective absorbance
- databases for calibrations, processing and storage of measurement data.
RA-915M mercury analyzer with RP-91NG attachment is covered by a full 1-year warranty.
Upon request, installation and commissioning of the equipment can be carried out at customer’s site by our service engineers or by a certified distributor. Support and training of operators, meeting customer’s specific needs, are provided by highly qualified application specialists.
| Measurement principle | Atomic absorption spectrometry at 254 nm with Zeeman correction of background absorption |
| Detection limit | 0.5 ng/m3 |
| Measurement range | 0 – 2000 μg/m3 |
| Sampling flow rate | 1 – 10 L/min |
| Analysis time | Direct online |
| Power supply | 100 – 240 VAC 50 – 60 Hz |
| Power consumption | 35 W (RA-915M analyzer) 35 W (RP-91NG attachment) |
| Dimensions | 470x220x110 mm (RA-915M analyzer) 320x290x160 mm (RP-91NG attachment) |
| Weight | 7 kg (RA-915M analyzer) 6.5 kg (RP-91NG attachment) |
Oil and gas, minerals
